China 24” frameless USB-C monitor Model: QW24DFI factory and manufacturers

24” frameless USB-C monitor Model: QW24DFI

Short Description:

Cost-effective Perfect Display office/stay at home productive monitor.
1.Easy to make your Phone become your PC, Project your mobile phone and laptop to the monitor via a USB-C cable.
2.45W Power Delivery via USB-C cable, working at the same time charge your PC notebook.
3.Perfect Display Private Molding,height adjustable stand optional.

Send email to us Product Manual Video

Features

Specification

Key Features

● 24/27" IPS panel with FHD/QHD high resolution.

● 75Hz high refresh rate optional.

● USB-C provides 45W power delivery for your phone or laptop.

● Height adjustable stand optional is more ergonomic.

● HDMI +DP +USB-C Technology.

Technical

Model No.:		QW24DFI	QW27DFI	QW27DQI
Display	Screen Size	23.8" IPS	27" IPS	27" IPS
	Backlight type	LED	LED	LED
	Aspect Ratio	16：9	16：9	16：9
	Brightness (Typical)	250 cd/m²	250 cd/m²	250 cd/m²
	Contrast Ratio (Typical)	1,000,000:1 DCR (1000:1 Static CR)	1,000,000:1 DCR (1000:1 Static CR)	1,000,000:1 DCR (1000:1 Static CR)
	Resolution (Max.)	1920 x 1080 @ 75Hz	1920 x 1080 @ 75Hz	2560 x 1440 @ 75Hz
	Response Time (Typical)	8ms(G2G)	8ms(G2G)	8ms(G2G)
	Viewing Angle (Horizontal/Vertical)	178º/178º (CR>10) ， IPS	178º/178º (CR>10) ， IPS	178º/178º (CR>10) ， IPS
	Color Support	16.7M, 8Bit, 72% NTSC	16.7M, 8Bit, 72% NTSC	16.7M, 8Bit, 72% NTSC
Signal input	Video Signal	Analog RGB/Digital	Analog RGB/Digital	Analog RGB/Digital
	Sync. Signal	Separate H/V, Composite, SOG	Separate H/V, Composite, SOG	Separate H/V, Composite, SOG
	Connector	HDMI + DP+ USB-C	HDMI + DP+ USB-C	HDMI + DP+ USB-C
Power	Power Consumption	Typical 22W	Typical 28W	Typical 32W
	Stand By Power (DPMS)	<0.5W	<0.5W	<0.5W
	Type	AC 100-240V 50/60HZ	AC 100-240V 50/60HZ	AC 100-240V 50/60HZ
	Power delivery	PD 45W	PD 45W	PD 45W
Features	Plug & Play	Supported	Supported	Supported
	Bezeless Design	3 side Bezeless Design	3 side Bezeless Design	3 side Bezeless Design
	Cabinet Color	Matt Black	Matt Black	Matt Black
	VESA Mount	75x75mm	100x100mm	100x100mm
	Low Blue Ligth	Supported	Supported	Supported
	Flicker Free	Supported	Supported	Supported
	Audio	2x2W	2x2W	2x2W
Accessories		Power cable, user's manual, USB C cable, HDMI cable
MOQ		500	500	500

Are you still using monitor without USB-C connector in 2022?

1. Connect with your switch/laptop/mobile via one USB-C cable.
2. 45w fast power delivery, Reverse charging for your electronic equipment.

Advantage of IPS Panel

1. 178°Wide viewing angle, Enjoy the same high-quality picture performance from every angle.

2. 16.7M 8 Bit, 90% of DCI-P3 Color Gamut is perfect for rendering/ editing.

75Hz high refresh rate satisfy both gaming and working

The first thing we need to establish is “What exactly is refresh rate?” Fortunately it isn’t very complex. Refresh rate is simply the number of times a display refreshes the image it shows per second. You can understand this by comparing it to frame rate in films or games. If a film is shot at 24 frames per second (as is the cinema standard), then the source content only shows 24 different images per second. Similarly, a display with a display rate of 60Hz shows 60 “frames” per second. It’s not really frames, because the display will refresh 60 times each second even if not a single pixel changes, and the display only shows the source fed to it. However, the analogy is still an easy way to understand the core concept behind refresh rate. A higher refresh rate therefore means the ability to handle a higher frame rate. Just remember, that the display only shows the source fed to it, and therefore, a higher refresh rate may not improve your experience if your refresh rate is already higher than the frame rate of your source.

What is HDR?

High-dynamic range (HDR) displays create deeper contrasts by reproducing a higher dynamic range of luminosity. An HDR monitor can make highlights look brighter and deliver richer shadows. Upgrading your PC with an HDR monitor is worth it if you play video games with high-quality graphics or watch videos in HD resolution.

Without getting too deep into the technical details, an HDR display produces greater luminance and color depth than screens built to meet older standards.

Product pictures

Freedom & Flexibility

The connections you need to connect to the devices you want, from laptops to soundbars. And with 100x100 VESA, you can mount the monitor and create a custom workspace that’s uniquely yours.
